sv1-34526
intel celeron j3455处理器, 6*com, 4*usb 3.0, 7*usb 2.0, 2*lan, 1*msata, 2*m.2
- 采用intel apollo lake celeron j3455处理器
- 6*com, 后i/o提供4*usb 3.0, 4*usb 2.0, 2*千兆网口
- 1*vga, 1*hdmi, 1*lvds/edp, 支持三显
- 1*msata 4g, 2*m.2支持sata和wifi bt
- mini-itx, dc 12v供电
规格
|
general |
|
|
cpu |
intel® celeron® j3455 cpu, quad-core, up to 2.3 ghz, tdp 10w cpu can be customized into intel® celeron® j3355, n3350, n3450 |
|
memory |
ddr3l-1866, 1*so-dimm, up to 8 gb |
|
storage |
1*sata 3.0, 1*msata 1*m.2 (key-b, 2242, sata) |
|
expansion interface |
1*mini-pcie (msata 4g) 1*m.2 (key-e, 2230, wifi bt) |
|
bios |
ami uefi bios |
|
system |
windows 10, linux |
|
i/o interface |
|
|
ethernet |
2*realtek® 1gbps pcie ethernet controller, rj45 |
|
serial |
4*rs232, 2*rs232/rs485 |
|
usb |
4*usb 3.0, up to 7*usb 2.0 |
|
audio |
realtek® 5.1 channel hda codec, with mic/line-out |
|
ps/2 |
1*ps/2 header (keyboard & mouse) |
|
parallel |
1*lpt header |
|
gpio |
8*programmable gpio |
|
display |
|
|
display interface |
1*vga: max resolution up to 1920*1200@60hz 1*hdmi: max resolution up to 1920*1200@60hz 1*lvds/edp: lvds, dual channel 24 bit, max resolution up to 1920*1200@60hz edp, max resolution up to 1920*1200@60hz |
|
multiple display |
triple |
|
mechanical & environment |
|
|
dimension |
170*170mm |
|
power input |
dc 12v |
| temperature |
operation: 0℃~60℃, storage: -20℃~75℃ |
|
relative humidity |
operation: 10%~90%, storage: 5%~95%, non-condensing |
