scm-c1152
核心模块, 第11代intel core或celeron处理器 (tiger lake)
- scm (seavo compute module) 核心模块
- 采用第11代intel core或celeron处理器 (tiger lake)
- 支持ddr4内存, 提供2*intel千兆网卡, 可选emmc
- 通过b2b连接器提供丰富的i/o与显示资源
- 载板可快速定制, 灵活选配scm模块
- 85*95mm
规格
|
general |
|
|
cpu |
intel® 11th coretm i7-1165g7, i5-1135g7, i3-1115g4 28w default, 12w/15w bios optional or celeron® 6305e cpu |
|
memory |
ddr4-3200, 1*so-dimm, up to 32 gb |
|
bios |
ami uefi bios |
|
system |
windows 10, linux |
|
i/o |
|
|
ethernet |
2*intel® 1gbps pcie ethernet controller |
|
audio |
1*realtek® alc662 5.1 channel hda codec |
|
high speed signal |
4*usb 3.0, 1*pcie x4 (cpu), 4*pcie x1, 2*sata |
|
usb 2.0 |
8*usb 2.0 |
|
serial |
6*ttl |
|
gpio |
8*programmable gpio |
|
others |
1*lpc, 1*sm bus, 1*i2c, 1*usb oc, 1*fan control, 1*power control, power ok |
|
display |
|
|
display |
1*edp/lvds, 1*vga, 1*ddi1, 1*ddi2 ddi can be set to dp/hdmi/dvi |
|
multiple display |
triple |
|
mechanical & environment |
|
|
dimension |
85*95mm |
|
power input |
5v |
| temperature |
operation: 0℃~60℃, storage: -25℃~75℃ |
|
relative humidity |
operation: 10%~90%, storage: 5%~95%, non-condensing |
